Main features
- Able to operate with polymers at different viscous levels together with solvents and acids
- Made of non-corrosive material Stainless steel 316
- Come with controllers to adjust desired temperature
- Accurate casting thickness control
Specifications
| Dope formation tank | |
| Tank capacity | 10L, 5L and 2.5L |
| Pressure rating | 3 bar |
| Material | Stainless steel 316 |
| Heating range | 0 to 100°C |
| Agitator speed | up to 500 RPM |
| Dope transfer gear pump | |
| flow rate | 0.1 to 5 L/min |
| Viscosity range | 1 to 100,000 centi Poise (cP) |
| Pressure outlet | 1 to 10 bar |
| Doctor blade assembly | |
| Cast size | up to 500 mm |
| Moving velocity | 0.1 to 15 m/min |
| Casting thickness | 10 to 300 micron |
| Casting thickness accuracy | +/- 5 micron |
| Gelation tank | |
| Size | 2500 x 800 x 1000 mm |
| Heating range | up to 70°C |
| Cooling range | 2 to 25°C |
| Air gap | 200 mm |
| Winder and Collector | |
| Diameter | up to 400 mm |
| Speed | 0 to 100 RPM |
| Max load | up to 100 KG |
